NYZK Tank Side Indicator IP66 Ex db IIC T6 Gb

Name: NYZK Tank Side Indicator IP66 Ex db IIC T6 Gb
Brand: NUOYINGJIAYE
Price: 450 USD

Buy cheap NYZK Tank Side Indicator IP66 Ex db IIC T6 Gb product

Brand Name : NUOYINGJIAYE

Model Number : NYRD702

Certification : CE

Place of Origin : Xi'an, Shaanxi，China

MOQ : 1 pcs

Price : $450 to $1700 /pcs

Payment Terms : T/T

Supply Ability : 1000 pcs/ pre month

Delivery Time : 7 working days

Packaging Details : Carton, 60cm×30cm×30cm

Typical application : No mixing of liquid, dust

Antenna material : Pole type, PTFE, 304(optional)

Measuring range : 6m

Medium temperature : -40~+130℃,-40~+250℃

Process connection : Thread, flange (optional)

Measuring accuracy : 0.05%-0.1%F.S

Process pressure : -0.1~4.0MPa

Contact Now

Explosion Proof Water Tank Side Remote Control Indicator Power Plant 4-20 mA Radar Level Meter Field Display Controller

NYZK Product Details

Product Parameters

NYZK Tank Side Indicator IP66 Ex db IIC T6 Gb

Typical application	Tank-side display and control
Case Material	Cast aluminum, stainless steel (optional)
Measuring accuracy	0.05%-0.1%F.S
Power supply	(12-36)VDC(±30%)
Medium temperature	-25~+125℃
Process connection	Flange, thread (optional)
Process pressure	-0.1~2.0MPa
Explosion-proof grade	Exia II CT6(optional)

Products Description

NYZK Tank Side Display Working Principle

NYGP type tank side display meter (hereinafter referred to as "display meter") is mainly used to output 4-20mA without digital display or with digital display but not easy to observe the auxiliary display of the field instrument.
The display instrument should be installed in the easy-to-observe location next to the tank, so that it is convenient to observe the use of nearby.

NP-93420-IB Pressure Sensor Transmitter Design Feature

1. Directly serialized into 4-20mA circuit, no need for external power supply.
2. Dot matrix LCD display, capable of displaying different parameter names and units, flexible application.
3. Membrane keys, convenient for setting parameters in close proximity.
4. Suitable for use with instruments outputting 4 to 20mA.
5. With Exd II CT6/Exia II CT6 explosion-proof performance, it can be used in various flammable and explosive areas such as Zone 0 (must be powered by safety grid), Zone 1, Zone 2, etc.
